Engineering Built for Reliability
Smart sensors, autonomous navigation and industrial-grade components
Advanced SLAM Navigation System
Our proprietary SLAM (Simultaneous Localization and Mapping) algorithm combines lidar, vision and IMU data for centimeter-level positioning accuracy in complex industrial environments. The system builds and maintains high-resolution facility maps while continuously tracking the robot's precise location.
Multi-Sensor Fusion
360° lidar (10Hz scan rate), stereo vision cameras, 9-axis IMU and wheel odometry combined using Kalman filtering for robust localization.
Positioning accuracy: ±2cm in mapped environments
Dynamic Obstacle Avoidance
Real-time detection and classification of static and moving obstacles. Automatic speed adjustment and path replanning within 100ms response time.
Detection range: 0.05m - 8m radius
Intelligent Path Planning
Coverage path planning algorithms optimize cleaning efficiency while accounting for facility constraints, traffic patterns and no-go zones.
Coverage efficiency: >95% in typical facilities
Industrial-Grade Sensor Array
Engineered for continuous operation in demanding commercial environments
360° Lidar System
Industrial-grade rotating lidar with 10Hz scan rate provides continuous 360° environmental awareness with 2cm range resolution.
- • Range: 0.05m - 8m
- • Angular resolution: 0.25°
- • IP54 rated for dust/water
- • 50,000+ hour MTBF
Stereo Vision Cameras
Dual HD cameras (1920×1080) with neural network processing for real-time object detection and classification.
- • 120° horizontal FOV
- • 30 FPS processing rate
- • Person/vehicle detection
- • Low-light capability (0.1 lux)
Lithium-Ion Battery System
High-capacity LiFePO4 cells with intelligent BMS for extended runtime and cycle life.
- • 8-10 hour continuous runtime
- • 2-2.5 hour fast charging
- • 3,000+ charge cycles
- • Auto-docking capability
Safety-Critical Control Systems
CE-certified compliance with EN ISO 13849-1 (PLd), EN 1525:2024 and EU Machinery Directive 2006/42/EC
Redundant Emergency Stop System
Dual-channel safety-rated emergency stop circuitry with hardware interlocks. Physical e-stop buttons accessible from all sides.
Response time: <50ms | Safety rating: Category 3, PLd per ISO 13849-1
Multi-Layer Collision Prevention
Triple-redundant obstacle detection: lidar, vision and proximity sensors. Automatic stop if any sensor detects obstacle within safety zone.
Safety zone: 30cm radius | Detection confidence: 99.9%
Adaptive Speed Control
AI-based person detection triggers automatic speed reduction from 1.2 m/s to 0.3 m/s when humans are detected within 2m proximity.
Max speed: 1.2 m/s | Reduced speed: 0.3 m/s near people
Certified Compliance Documentation
Complete technical construction files, risk assessments and EU Declarations of Conformity provided with each unit.
Standards: EN 1525:2024, ISO 3691-4, EN ISO 13849-1
Enterprise Fleet Management Platform
Cloud-based fleet control with real-time telemetry, analytics and remote management capabilities
- 01
Real-Time Fleet Telemetry
Live tracking of robot position, battery level, cleaning progress and operational status with 1-second update intervals. WebSocket-based push notifications for critical events and alarms.
Data retention: 90 days | API access: REST + WebSocket
- 02
Advanced Schedule Management
Zone-based scheduling with recurring patterns, priority levels and conflict resolution. Automatic task allocation across available fleet members with load balancing.
Schedule granularity: 15-minute intervals | Max zones: 100 per facility
- 03
Performance Analytics & Reporting
Comprehensive dashboards showing coverage area, cleaning efficiency, battery cycles and operational costs. Exportable reports in PDF/CSV for facility management and sustainability reporting.
Metrics tracked: 40+ KPIs | Report formats: PDF, CSV, JSON
- 04
Remote Diagnostics & Control
Remote access for troubleshooting, software updates (OTA) and configuration changes. Secure SSH tunnel with role-based access control and audit logging.
Encryption: TLS 1.3 | Authentication: OAuth 2.0 + 2FA
- 05
Multi-Site Management
Unified dashboard for managing fleets across multiple facilities and geographic locations. Hierarchical user permissions for corporate, site and operator-level access.
Max sites: Unlimited | User roles: 5 permission levels
Technical Specifications
Detailed specifications for engineering and procurement teams
Navigation & Control
Power & Performance
Sensors & Perception
Connectivity & Compliance
Experience the Technology
Schedule a technical demo and site assessment to evaluate our cleaning robots for your facility
